HMI Touch Screen WECON LEVI-777T
Chenglin Ding
Contact person
Basic Information
| Place of Origin | Fujian China (Mainland) |
|---|---|
| Brand Name | WECON |
| Model Number | HMI LEVI-777T |
Mainboard: RISC CPU 400MHZ,32M FLASH, 64 SDRAM Display: Display Size: 7inch Resolution: 800×480 CSTN LCD65536 Colors Interface: Support RS232/RS485/RS422 Two Serial ports Storage: Support USB Disk, CF CardModel LEVI777TGeneral specificationsDisplay Size7'InchTrue ColorTFT(152.0×91.0mm)Resolution800×480 pixelsColors65536 ColorsBrightness300cd/m2BacklightLEDTouch Panel4 Line precision resistance(Surface hardness 4H)Backligh Life50000 HoursCPU32-bit 200MHz RISCStorage and Memory32M FLASH + 64M SDRAMRecipe and RTCsupportPrinting PortSerial PortEthernetYesProgram DownloadOne USB SLAVECommunicating PortCOM1:RS232/RS422/RS485, COM2:RS232/RS485Electrical SpecificationsRated Power<10WRated VoltageDC24VVoltage Range12 28VDCPower Interval Allowed<5msInsulation Resistance>20MΩ 500VDCWithstand Voltage500V AC < 1 minuteStructure SpecificationsShell ColorBlackShell MaterialABS PlasticShape Size205.7×155.7×46.4mmInstallation Size192×142mmWeight0.7kgEnviroments SpecificationsWork Temperature0 50°CWork Humidity10 90%RH(No Condensation)Storage Temperature0 50°CStorage Humidity10 90%RH(No Condensation)ShockProof test10 25 Hz (X,Y,ZOrientation 2G/30minute)Cooling MethodNaturalProducts CertificationsDegree of Panel ProtectionIP65CEEN61000-6-2:2005, EN61000-6-4: 2007 StandardFCC CompatibilityFCC Class A
-
